Lewden 100/30/2B Type B 100A 30mA 230V 2 Pole RCD

Description

Type B 100A 30mA 230V 2 Pole RCD

Lewden 100/30/2B

  • 100A 2-pole residual current device
  • 30mA sensitivity for personal protection
  • 6kA short-circuit withstand capacity
  • Type B: detects AC, pulsating & smooth DC
  • Suitable for EV charging & inverter circuits
  • TN-S, TN-C-S & TT earthing compatible
  • DIN rail mounting
  • BS EN 61008-1 compliant

The Type B 100A 30mA 230V 2 Pole RCD provides advanced electrical protection for modern residential, commercial and industrial installations. Featuring 30mA sensitivity, it helps protect against electric shock while detecting AC, pulsating DC and smooth DC residual currents. Its Type B protection makes it particularly suitable for EV charging points, inverter systems, solar installations and other equipment using power electronics. Designed for DIN rail mounting, this 2 pole RCD offers a 6kA short-circuit withstand capacity and is compatible with TN-S, TN-C-S and TT earthing systems. Manufactured to BS EN 61008-1 standards for dependable safety and performance.

.

For Cables 1-35mm2
Frequency 50Hz
Poles 2
Residual Current 30mA
Rated Operating Voltage 230V
Mounting Din Rail Mounting
Rated Current 100A
RCD Class B

Read more

Lewden 100/30/2B Type B 100A 30mA 230V 2 Pole RCD

Product form

SKU: 100/30/2B

Type B 100A 30mA 230V 2 Pole RCD Lewden 100/30/2B 100A 2-pole residual current device 30mA sensitivity for personal protection... Read more

Free pickup in our shop(s)

£75.30 ex VAT £90.36 inc VAT

Next day delivery

    • Guaranteed secure & safe checkout.

      shop pay
    • Shipped today? Order within: Sep 26, 2026 15:00:00 +0100
    • Free shipping on all orders above £100 + vat
      Specification
    For Cables 1-35mm2
    Frequency 50Hz
    Poles 2
    Residual Current 30mA
    Rated Operating Voltage 230V
    Mounting Din Rail Mounting
    Rated Current 100A
    RCD Class B
      Downloads

    Description

    Type B 100A 30mA 230V 2 Pole RCD

    Lewden 100/30/2B

    • 100A 2-pole residual current device
    • 30mA sensitivity for personal protection
    • 6kA short-circuit withstand capacity
    • Type B: detects AC, pulsating & smooth DC
    • Suitable for EV charging & inverter circuits
    • TN-S, TN-C-S & TT earthing compatible
    • DIN rail mounting
    • BS EN 61008-1 compliant

    The Type B 100A 30mA 230V 2 Pole RCD provides advanced electrical protection for modern residential, commercial and industrial installations. Featuring 30mA sensitivity, it helps protect against electric shock while detecting AC, pulsating DC and smooth DC residual currents. Its Type B protection makes it particularly suitable for EV charging points, inverter systems, solar installations and other equipment using power electronics. Designed for DIN rail mounting, this 2 pole RCD offers a 6kA short-circuit withstand capacity and is compatible with TN-S, TN-C-S and TT earthing systems. Manufactured to BS EN 61008-1 standards for dependable safety and performance.

    .

    For Cables 1-35mm2
    Frequency 50Hz
    Poles 2
    Residual Current 30mA
    Rated Operating Voltage 230V
    Mounting Din Rail Mounting
    Rated Current 100A
    RCD Class B

    Read more
